HZ-2

This is the ideal device for mobile activity. Changing to different cable diameters can be effected rapidly.

Because of its automated cable centering, work is greatly simplified. The unit is easy to handle, which is an added advantage.

Technical Data

• Number of Printing Wheels : Character Height 1,5 mm to 2,3 mm 10 pieces  / Character Height 2,5 mm to 4,0 mm 7 pieces

• Working range cable outer-ø : cable ø minimum 1,5 mm  / cable ø maximum 25,0 mm

• Signs per printing wheel : Character Height 1,5 mm - bis 2,3 mm 28 signs (Standard) / Character Height 2,5 mm  - bis 4,0 mm 20 signs (selectable)

• Number of Markings per foil : min. 12'000 / max. 20'000 markings

• Foil type : Available in different colors and quality

• Dimensions : 230 x 70 x 290

• Weight : 1,400 kg (3.0 lbs)
